The new pre-driver can control BLDC motors by pulse-width modulation (PWM) input only, without any need for high-performance MCUs and software.
TB9062FNG has an automatic duty generation function that adjusts the output PWM duty cycle to suit the battery voltage (VBAT) at startup, and a soft speed changing function that prevents stalls by suppressing sudden changes in output PWM duty. These functions, which were absent from Toshiba’s earlier products, contribute to stable motor control.
TB9062FNG does not require any software development as it is controlled by a hard-wired logic circuit. VBAT over voltage detection, VBAT under voltage detection, over current protection, and thermal shutdown circuits are also implemented. The operating temperature range is -40°C to 125°C, highly suited to automotive applications.
* Simplified motor control by hard-wired logic circuit.
Eliminates need for software development and secures motor control by PWM input only.
* Automatic PWM duty control at startup
Stable motor rotation at startup is secured by adjusting the PWM duty to the VBAT.
* Automatic soft speed changing control
Prevents stalls by suppressing sudden changes of output PWM duty cycle.
* Several abnormality detection functions with flag output.
VBAT over voltage detection, VBAT under voltage detection, thermal shutdown circuit, and current limitation
Automotive electric pumps: water pumps, oil pumps and fuel pumps; automotive electric fans
Part number TB9062FNG
Power supply voltage
range) 6.5V to 16.6V
Operating temperature -40°C to 125°C
Package SSOP24-P-300-0.65A (7.8mm×7.6mm)
Drive control Sensorless 120 degree commutation
Speed control input PWM input signal
Abnormality detections VBAT over voltage detection; VBAT under voltage detection; thermal shutdown circuit; current limitation
Reliability Toshiba standard
Mass production December 2019
