TOKYO--(Antara/BUSINESS WIRE)-- Toshiba Electronic Devices & Storage Corporation (“Toshiba”) has launched “TLP2363,” a 10Mbps high-speed communication logic output photocoupler for 24V digital input interfaces of Programmable Logic Controllers (PLCs). Shipments start today.

This press release features multimedia. View the full release here: https://www.businesswire.com/news/home/20200127005229/en/

The new photocoupler’s specifications include both the minimum and maximum values of its threshold input current at its operating temperature range (-40 to 105℃). Use of the photocoupler in combination with appropriate resistors for current control realizes a 24V digital input module that follows IEC 61131-2 Type 1[1] specifications.

In addition, the new product’s circuit suppresses chattering noise so that its output is clearly either “low” or “high,” even with a slow input signal with a long (60s or less) rise or fall time. This eliminates the need for a waveform shaping circuit in the output part, reducing the number of components.

The photocoupler is packaged in the thin 5pin SO6, and has a maximum height of 2.3mm. Its slim shape brings greater freedom to component layout on printed circuit boards.

Applications

• High-speed digital interfaces (PLCs, measuring equipment and control equipment, etc.)

Features

• Minimum value of threshold input current : IFHL=0.3mA (min)
• Maximum value of threshold input current : IFHL=2.4mA (max)
• Wide operating temperature range: Topr = -40 to 105℃
• Data transfer rate: 10Mbps (typ.)
• High immunity to a slow input (maximum 60s)
• Operable for 3.3V / 5V supply voltage systems

Main Specifications
(Unless otherwise specified, @Ta= -40 to 105℃)
Part
number    Package    Absolute
maximum ratings    Electrical
characteristics    Switching
characteristics    Isolation
Characteristic    Stock
Check &
Purchase

    Name    Height
max
(mm)    Operating
temperature
Topr
max
(℃)    Output
current
IO
(mA)    Supply
current
ICCH, ICCL
max
(mA)    Threshold
input
current
(H/L)
IFHL
min/max
(mA)    Propagation
delay time
tpHL, tpLH
max
(ns)    Common
-mode
transient
immunity
CMH, CML
min
@Ta=25℃
(kV/μs)    Isolation
voltage
min
@Ta=25℃
(Vrms)
TLP2363
5pin SO6    2.3    105    25    4    0.3/2.4    80    ±20    3750    Buy Online

Note:
[1] Specifies the requirements and tests for PLC devices

Follow the link below for more on the new product.
TLP2363
https://toshiba.semicon-storage.com/info/lookup.jsp?pid=TLP2363

Follow the link below for more on Toshiba’s optical devices line-up.
https://toshiba.semicon-storage.com/ap-en/product/opto.html

To check availability of the new products at online distributors, please visit:
TLP2363
https://toshiba.semicon-storage.com/ap-en/semiconductor/where-to-buy/stockcheck.TLP2363.html
