TOKYO--(Antara/BUSINESS WIRE)-- Toshiba Electronic Devices & Storage Corporation (“Toshiba”) has launched “TLP2363,” a 10Mbps high-speed communication logic output photocoupler for 24V digital input interfaces of Programmable Logic Controllers (PLCs). Shipments start today.
This press release features multimedia. View the full release here: https://www.businesswire.com/news/home/20200127005229/en/
The new photocoupler’s specifications include both the minimum and maximum values of its threshold input current at its operating temperature range (-40 to 105℃). Use of the photocoupler in combination with appropriate resistors for current control realizes a 24V digital input module that follows IEC 61131-2 Type 1 specifications.
In addition, the new product’s circuit suppresses chattering noise so that its output is clearly either “low” or “high,” even with a slow input signal with a long (60s or less) rise or fall time. This eliminates the need for a waveform shaping circuit in the output part, reducing the number of components.
The photocoupler is packaged in the thin 5pin SO6, and has a maximum height of 2.3mm. Its slim shape brings greater freedom to component layout on printed circuit boards.
• High-speed digital interfaces (PLCs, measuring equipment and control equipment, etc.)
• Minimum value of threshold input current : IFHL=0.3mA (min)
• Maximum value of threshold input current : IFHL=2.4mA (max)
• Wide operating temperature range: Topr = -40 to 105℃
• Data transfer rate: 10Mbps (typ.)
• High immunity to a slow input (maximum 60s)
• Operable for 3.3V / 5V supply voltage systems
(Unless otherwise specified, @Ta= -40 to 105℃)
number Package Absolute
maximum ratings Electrical
5pin SO6 2.3 105 25 4 0.3/2.4 80 ±20 3750 Buy Online
 Specifies the requirements and tests for PLC devices
Follow the link below for more on the new product.
Follow the link below for more on Toshiba’s optical devices line-up.
To check availability of the new products at online distributors, please visit:
